Features
Wide range of materials Aluminium Bronze, Super Duplex, Stainless Steel, Titanium, 6MO, Hastelloy®, Monel®, Inconel® & Gunmetal.
Usage for petrochemical, sea water & offshore markets
During normal working of the main the valve releases the air which accumulates under pressure. With the main in operation, the float is normally against its seat. As air enters the body the water level is depressed until a level is reached when the float drops from its seat, which allows air to escape. The consequent rise in water level returns the float to its seat.
Efficient low pressure sealing at 0.2bar.
Lightweight design.
2.3mm (4.1mm2) orifice.
Suitable for:
Valve type:
PART | PARTS | AVAILABLE MATERIALS |
1 | Body | Aluminium Bronze, Super Duplex, Stainless Steel, Titanium, 6MO, Hastelloy, Monel, Inconel Gunmetal |
2 | Cover | Aluminium Bronze, Super Duplex, Stainless Steel, Titanium, 6MO, Hastelloy, Monel, Inconel Gunmetal |
3 | Float | ABS & Stainless Steel |
4 | Orifice Plug | ABS & Stainless Steel |
5 | Retaining Nut | ABS & Stainless Steel |
6 | Orifice Seal | EPDM & Viton |
7 | Stop Screw | Stainless Steel |
8 | Hinge Pin | Stainless Steel |
9 | Body Joint | EPDM & Viton |
10 | Plug Joint | EPDM & Viton |
11 | Bolt & Nut | Aluminium Bronze, Super Duplex, Stainless Steel, Titanium, 6MO, Hastelloy, Monel, Inconel Gunmetal |
12 | Nipple | Aluminium Bronze, Super Duplex, Stainless Steel, Titanium, 6MO, Hastelloy, Monel, Inconel Gunmetal |
